Bay Star 3416 Description

Newmar Bay Star Class A gas motorhome 3416 highlights:

  • Two Pantries
  • King Bed Slide Out
  • Comfort Lounge Sofa
  • 10 Cu. Ft. Norcold Refrigerator
  • Power Awning with LED Lights



This motorhome with dual opposing slides in the main living area will provide your crew with tons of space to relax. You'll also find a slide out in the private bedroom suite, along with a king bed, a Samsung LED TV, and a shelf to store books or jewelry. There is a comfort lounge sofa, a booth dinette, and a tri-fold sofa in the main living area that will be perfect for guests, and the Samsung TV on power lift will allow you to enjoy movie night. In the morning, prepare breakfast on the recessed three burner cooktop before heading out for the day, and the full bath will allow you to clean up after a day outdoors!



Each Bay Star Class A gas motorhome by Newmar delivers a smooth ride thanks to the standard electronic stability control, along with the 7.3-liter V8 engine with 450 HP and 468 lb./ft. of torque and heavy duty sway bars. The exterior is sure to turn heads with its full-paint Masterpiece Finish, and you'll have three interior decor choices and three wood choices to truly make the coach your own. Each model includes newly styled Williamsburg furniture, luxurious vinyl tile flooring, polished solid surface countertops in the kitchen, plus many more comforts. Head outside to find lit basement storage, a 5.5kW Onan generator with remote switch, and smart level hydraulic leveling jacks with a Bluetooth compatible touch pad for set up easy as 1-2-3! You can further customize your coach with the many options that are offered, such as the optional exterior entertainment center, the optional fireplace in the living room, and the optional Whirlpool refrigerator to name a few!

Bay Star 3416 Specifications

Sleeps 7
Slides 3
Length 34 ft 11 in
Ext Width 8 ft 6 in
Ext Height 12 ft 8 in
Int Height 6 ft 8 in
Interior Color Gable, Ryder, Urban
Exterior Color Gable, Ryder, Urban
Hitch Weight 5000 lbs
Gross Weight 24000 lbs
Dry Weight 20744 lbs
Cargo Weight 3256 lbs
Fresh Water Capacity 75 gals
Grey Water Capacity 60 gals
Black Water Capacity 40 gals
Furnace BTU 40000 btu
Generator 5.5kW Cummins Onan
Fuel Type Gas
Engine 7.3L V8
Chassis Ford F-53
Horsepower 350 hp
Fuel Capacity 80 gals
Wheelbase 234 in
Available Beds King
Torque 468 ft-lb
Refrigerator Type Norcold
Refrigerator Size 10 cu ft
Cooktop Burners 3
Shower Size 40" x 30"
Number of Awnings 1
Axle Weight Front 9000 lbs
Axle Weight Rear 15500 lbs
LP Tank Capacity 25 lbs
Water Heater Capacity 6 gal
Water Heater Type Gas/Electric
AC BTU 27000 btu
TV Info LR Samsung LED TV Lift, BR Samsung LED TV
Awning Info Carefree Travel'R Side Awning with Strip Lighting
Gross Combined Weight 30000 lbs
Shower Type Standard
