New 2023 Bay Star 3014 Motor Home Class A

* The images displayed may represent all Bay Star models

Shop Bay Star 3014 For Sale

Bay Star 3014 Description

Newmar Bay Star Class A gas motorhome 3014 highlights:

  • Full-Wall Slide
  • Shower Skylight
  • Booth Dinette
  • Swivel Seats
  • Bedroom Shirt Wardrobe



Enjoy luxury at every turn in this Bay Star motorhome. The full-wall slide provides added space, along with the queen bed slide out in the rear private bedroom. You can easily prepare meals on the recessed three burner cooktop, or use the stainless steel convection microwave, and the pantry will be perfect for dry goods or snacks. This model includes a tri-fold sofa and a comfy booth dinette for seating and sleeping space, plus there is a Samsung LED TV in the living room and bedroom so you can watch your favorite shows. You'll find storage space up front, plenty of overhead compartments, plus lit basement storage.



Each Bay Star Class A gas motorhome by Newmar delivers a smooth ride thanks to the standard electronic stability control, along with the 7.3-liter V8 engine with 450 HP and 468 lb./ft. of torque and heavy duty sway bars. The exterior is sure to turn heads with its full-paint Masterpiece Finish, and you'll have three interior decor choices and three wood choices to truly make the coach your own. Each model includes newly styled Williamsburg furniture, luxurious vinyl tile flooring, polished solid surface countertops in the kitchen, plus many more comforts. Head outside to find lit basement storage, a 5.5kW Onan generator with remote switch, and smart level hydraulic leveling jacks with a Bluetooth compatible touch pad for set up easy as 1-2-3! You can further customize your coach with the many options that are offered, such as the optional exterior entertainment center, the optional fireplace in the living room, and the optional Whirlpool refrigerator to name a few!

Bay Star 3014 Specifications

Sleeps 5
Slides 2
Length 30 ft 11 in
Ext Width 8 ft 6 in
Ext Height 12 ft 8 in
Int Height 6 ft 8 in
Interior Color Axis, Burma, Colusa
Exterior Color Axis, Burma, Colusa
Hitch Weight 5000 lbs
Gross Weight 24000 lbs
Dry Weight 20200 lbs
Cargo Weight 3800 lbs
Fresh Water Capacity 75 gals
Grey Water Capacity 60 gals
Black Water Capacity 40 gals
Furnace BTU 40000 btu
Generator 5.5 kW Cummins Onan
Fuel Type Gas
Engine 7.3L V8
Chassis Ford F-53
Horsepower 350 hp
Fuel Capacity 80 gals
Wheelbase 210 in
Available Beds Queen
Torque 468 ft-lb
Refrigerator Type Norcold
Refrigerator Size 10 cu ft
Convection Cooking Yes
Cooktop Burners 3
Shower Size 40" x 30"
Number of Awnings 1
Axle Weight Front 9000 lbs
Axle Weight Rear 15500 lbs
LP Tank Capacity 25 gals
Water Heater Capacity 6 gal
Water Heater Type Gas/Electric
AC BTU 27000 btu
TV Info LR Samsung LED, BR Samsung LED
Awning Info Carefree Travel'r Power Side Awning w/Strip Lighting
Gross Combined Weight 30000 lbs
Shower Type Standard
Electrical Service 50 amp
